PG Series - Technical Parameters
Product Description
◆ Dimension Size: 64-200
◆ Gear Ratio Range: 3-100
◆ Accuracy Range: 1-3 arcmin (P1),3-5 arcmin (P2),5-7 arcmin (P3)
Features
◆ Unique flange output type, more flexible for mounting
◆ More compact, less mounting space.
◆ Less backlash, high positioning accuracy
◆ Double brace cage type planetary structure.
◆ Reliable and suit for frequently reversing.
◆ Bogie using tapered roller bearing (TRB), meet the heavy load requirements.
Parameter /Specification | Unit | PG64 | PG90 | PG110 | PG140 | PG200 | ||
---|---|---|---|---|---|---|---|---|
Max.Torque | Nm | 1.5* Rated Torque | ||||||
Emerg. Braking Torque | Nm | 2* Rated Torque | ||||||
Max. Radial Torque | N | 680 | 1700 | 3100 | 5650 | 6200 | ||
Max. Axial Torque | N | 340 | 875 | 1250 | 2275 | 3100 | ||
Torsional Stiffness | Nm/arcmin | 13 | 31 | 82 | 151 | 450 | ||
Max.Input Speed | rpm | 6000 | 6000 | 4500-6000 | 4000-5000 | 3000-4000 | ||
Rated Input Speed | rpm | 3300-5500 | 2600-4500 | 2300-4200 | 2000-3900 | 2000-3000 | ||
Noise | dB | |||||||
Aver. life | H | 20000 | ||||||
Full load-efficiency | % | L1≥95%, L2≥90% | ||||||
Backlash | P0 | L1 | arcmin | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 |
L2 | arcmin | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ||
P1 | L1 | arcmin | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | |
L2 | arcmin | ≤8 | ≤8 | ≤8 | ≤8 | ≤8 | ||
Rotary Interial | L1 | 4 | Kg.cm² | 0.13 | 0.51 | 2.87 | 7.54 | 23.4 |
5 | Kg.cm² | 0.13 | 0.47 | 2.71 | 7.42 | 23.4 | ||
7 | Kg.cm² | 0.13 | 0.45 | 2.62 | 7.14 | 23.4 | ||
10 | Kg.cm² | 0.03 | 0.44 | 2.57 | 7.03 | 21.8 | ||
20 | Kg.cm² | 0.03 | 0.23 | 0.47 | 2.71 | 21.8 | ||
L2 | 25 | Kg.cm² | 0.03 | 0.23 | 0.47 | 2.71 | 21.8 | |
35 | Kg.cm² | 0.03 | 0.23 | 0.47 | 2.71 | 21.8 | ||
40 | Kg.cm² | 0.03 | 0.23 | 0.47 | 2.71 | 21.8 | ||
50 | Kg.cm² | 0.03 | 0.2 | 0.44 | 2.57 | 21.8 | ||
70 | Kg.cm² | 0.03 | 0.2 | 0.44 | 2.57 | 21.8 | ||
100 | Kg.cm² | 0.03 | 0.2 | 0.44 | 2.57 | 21.8 |
Parameter/specifiction | PG64 | PG90 | PG110 | PG140 | PG200 | ||
---|---|---|---|---|---|---|---|
Rated Torque (Nm) | Stage | Ratio | |||||
L1 | 4 | 28 | 75 | 170 | 370 | 1020 | |
5 | 28 | 75 | 170 | 370 | 1020 | ||
7 | 28 | 75 | 120 | 370 | 880 | ||
10 | 18 | 60 | 120 | 240 | 685 | ||
L2 | 20 | 40 | 90 | 210 | 400 | 1020 | |
25 | 40 | 90 | 200 | 400 | 1020 | ||
35 | 40 | 90 | 210 | 400 | 1020 | ||
40 | 40 | 90 | 210 | 400 | 1020 | ||
50 | 40 | 90 | 220 | 400 | 1020 | ||
70 | 40 | 90 | 200 | 400 | 880 | ||
100 | 18 | 60 | 120 | 240 | 685 | ||
Protect Level | IP65 | ||||||
Environment Temp. | 45°C -- -15°C |
PG-64-L1
PG-90-L1
PG-90-L2
PG-110-L1
PR Series - Technical Parameters
Product Description
◆ First-stage reduction ratio can be done: 3,4,5,7,10 ◆ Second-stage reduction ratio can be done: 12,15,16,20,25,28,30,35,40,50,70,100 ◆ Rated torque: Torque Range from 30N.m to 650N.m ◆ Accuracy : 3-8arcmin
-
Series:
Parameter/Specification | Unit | PR60 | PR90 | PR120 | PR150 | PR180 | ||
---|---|---|---|---|---|---|---|---|
Max.Torque | Nm | 2* Rated Torque | ||||||
Emerg. Braking Torque | Nm | 3* Rated Torque | ||||||
Max. Radial Torque | N | 1100 | 2000 | 5500 | 9000 | 14200 | ||
Max. Axial Torque | N | 550 | 1000 | 2750 | 4500 | 7100 | ||
Torsional Stiffness | Nm/arcmin | 5 | 18 | 28 | 51 | 142 | ||
Max.Input Speed | rpm | 5000 | 5000 | 4500 | 4500 | 4000 | ||
Rated Input Speed | rpm | 3000 | 3000 | 3000 | 3000 | 3000 | ||
Noise | dB | ≤65 | ≤65 | ≤68 | ≤68 | ≤70 | ||
Aver. life | H | 20000 | ||||||
Full load-efficiency | % | L1≥96%, L2≥93% | ||||||
Backlash | P0 | L1 | arcmin | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 |
L2 | arcmin | ≤5 | ≤5 | ≤5 | ≤6 | ≤6 | ||
P1 | L1 | arcmin | ≤6 | ≤6 | ≤6 | ≤6 | ≤6 | |
L2 | arcmin | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ||
Rotary Interial | L1 | 3 | Kg.cm² | 0.135 | 0.65 | 3.13 | 12.41 | 29.15 |
4 | Kg.cm² | 0.136 | 0.52 | 2.79 | 7.66 | 24.78 | ||
5 | Kg.cm² | 0.136 | 0.45 | 2.55 | 7.66 | 23.76 | ||
7 | Kg.cm² | 0.13 | 0.47 | 2.32 | 7.54 | 23.68 | ||
10 | Kg.cm² | 0.073 | 0.39 | 2.28 | 7.57 | 23.68 | ||
L2 | 12 | Kg.cm² | 0.127 | 0.72 | 2.56 | 7.57 | 23.71 | |
15 | Kg.cm² | 0.073 | 0.52 | 2.4 | 7.55 | 23.73 | ||
20 | Kg.cm² | 0.074 | 0.37 | 1.65 | 7.57 | 23.66 | ||
25 | Kg.cm² | 0.074 | 0.37 | 1.58 | 7.46 | 23.66 | ||
28 | Kg.cm² | 0.074 | 0.35 | 1.57 | 7.46 | 23.58 | ||
40 | Kg.cm² | 0.078 | 0.37 | 1.58 | 7.38 | 23.54 | ||
50 | Kg.cm² | 0.078 | 0.36 | 1.57 | 7.29 | 23.52 | ||
100 | Kg.cm² | 0.079 | 0.5 | 1.5 | 7.2 | 23.46 |
Para. Spec. | PR60 | PR90 | PR120 | PR150 | PR180 | ||
---|---|---|---|---|---|---|---|
Stage | Ratio | ||||||
Rated Torque(Nm) | L1 | 3 | 30 | 115 | 208 | 424 | 558 |
4 | 45 | 142 | 320 | 650 | 1050 | ||
5 | 50 | 142 | 320 | 650 | 1200 | ||
7 | 50 | 110 | 230 | 550 | 1100 | ||
10 | 35 | 75 | 165 | 320 | 900 | ||
L2 | 12 | 115 | 208 | 424 | 588 | ||
15 | 142 | 208 | 424 | 588 | |||
16 | 45 | 142 | 320 | 650 | 1050 | ||
20 | 50 | 142 | 320 | 650 | 1050 | ||
25 | 50 | 142 | 320 | 650 | 1200 | ||
28 | 50 | 142 | 320 | 650 | 1050 | ||
30 | 115 | 208 | 424 | 588 | |||
35 | 50 | 142 | 330 | 650 | 1200 | ||
40 | 40 | 142 | 320 | 650 | 1050 | ||
50 | 35 | 142 | 320 | 650 | 1200 | ||
70 | 35 | 110 | 230 | 550 | 1100 | ||
100 | 35 | 75 | 165 | 320 | 900 | ||
Weight (Kg) | L1 | 1.6 | 4.5 | 8 | 17 | 35 | |
L2 | 2 | 6 | 11 | 22 | 43 |
PR-60-L1
PR-60-L2
PR-90-L1
PR-90-L2
PR-120-L1
PR-120-L2
PR-150-L1
PR-150-L2
PR-180-L1
PR-180-L2
PRL Series - Technical Parameters
Product Description
◆ First-stage reduction ratio can be done: 3,4,5,7,10
◆ Second-stage reduction ratio can be done: 9,12,15,16,20,25,28,30,35,40,50,70,100
◆ Rated torque: torque range from 30N.m to 650Nm
◆ Specific models are as follows: PRL160 PRL160-L1-3, PRL160-L1-4, PRL160-L1-5, PRL160-L1-7, PRL160-L1-10 PRL160-L2-9, PRL160-L2-12, PRL160-L2-20, PRL160-L2-16, PRL160-L2-20, PRL160-L2-25, PRL160-L2-28, PRL160-L2-30, PRL160 -L2-35, PRL160-L2-40, PRL160-L2-50, PRL160-L2-70, PRL160-L2-100
-
Series:
Parameter/specifacation | Unit | PRL60 | PRL80 | PRL90 | PRL120 | PRL140 | ||
---|---|---|---|---|---|---|---|---|
Max.Torque | Nm | 1.5* Rated Torque | ||||||
Emerg. Braking Torque | Nm | 2* Rated Torque | ||||||
Max. Radial Torque | N | 240 | 400 | 450 | 1240 | 2250 | ||
Max. Axial Torque | N | 220 | 420 | 430 | 1000 | 1500 | ||
Torsional Stiffness | Nm/arcmin | 1.8 | 4.7 | 4.85 | 11 | 22 | ||
Max.Input Speed | rpm | 8000 | 6000 | 6000 | 6000 | 4500 | ||
Rated Input Speed | rpm | 4000 | 3500 | 3500 | 3500 | 3000 | ||
Noise | dB | ≤58 | ≤60 | ≤60 | ≤65 | ≤68 | ||
Aver. life | H | 20000 | ||||||
Full load-efficiency | % | L1≥96%, L2≥94% | ||||||
Backlash | P0 | L1 | arcmin | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 |
L2 | arcmin | ≤5 | ≤5 | ≤5 | ≤6 | ≤6 | ||
P1 | L1 | arcmin | ≤6 | ≤6 | ≤6 | ≤8 | ≤8 | |
L2 | arcmin | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ||
Rotary Interial | L1 | 3 | Kg.cm² | 0.46 | 0.77 | 1.73 | 12.78 | 21.4 |
4 | Kg.cm² | 0.46 | 0.77 | 1.73 | 12.78 | 21.4 | ||
5 | Kg.cm² | 0.46 | 0.77 | 1.73 | 12.78 | 21.4 | ||
7 | Kg.cm² | 0.41 | 0.65 | 1.42 | 11.38 | 17.6 | ||
10 | Kg.cm² | 0.41 | 0.65 | 1.42 | 11.38 | 17.6 | ||
L2 | 12 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | |
15 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
20 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
25 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
28 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
40 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
50 | Kg.cm² | 0.34 | 0.58 | 1.25 | 11.48 | 15.7 | ||
100 | Kg.cm² | 0.34 | 0.58 | 1.25 | 11.48 | 15.7 |
Parameter/Specification | PR60 | PR90 | PR120 | PR150 | PR180 | ||
---|---|---|---|---|---|---|---|
Rated Torque(Nm) | Stage | Ratio | |||||
L1 | 3 | 27 | 50 | 96 | 161 | 392 | |
4 | 40 | 90 | 122 | 210 | 520 | ||
5 | 40 | 90 | 122 | 210 | 520 | ||
7 | 34 | 48 | 95 | 170 | 395 | ||
10 | 16 | 22 | 56 | 86 | 265 | ||
L2 | 9 | 27 | 50 | 96 | 161 | 392 | |
12 | 27 | 50 | 96 | 161 | 392 | ||
15 | 27 | 50 | 96 | 161 | 392 | ||
16 | 40 | 90 | 122 | 210 | 520 | ||
20 | 40 | 90 | 122 | 210 | 520 | ||
25 | 40 | 90 | 122 | 210 | 520 | ||
28 | 40 | 90 | 122 | 210 | 392 | ||
30 | 27 | 50 | 96 | 161 | 392 | ||
35 | 40 | 90 | 122 | 210 | 520 | ||
40 | 40 | 90 | 122 | 210 | 520 | ||
50 | 40 | 90 | 122 | 210 | 520 | ||
70 | 34 | 48 | 95 | 170 | 395 | ||
100 | 16 | 22 | 56 | 86 | 265 | ||
Weight (Kg) | L1 | 0.93 | 2.35 | 2.35 | 6.15 | 11.3 | |
L2 | 1.15 | 2.7 | 2.7 | 8 | 13.5 |
PRL-60-L1
PRL-60-L2
PRL-80-L1
PRL-80-L2
PRL-90-L1
PRL-90-L2
PRL-120-L1
PRL-120-L2
PRF Series - Technical Parameters
Product Description
◆ Specifications: There are 60 , 90 , 120 , 142
◆ Transmission ratio: 3 , 4 , 5 , 7 , 10 optional
◆ Rated torque: torque range from 30N.m to 650Nm
◆ Series: there is already a level, two
◆ Accuracy: 5-10arcmin
Features:
Flange, single support structure:◆ More sophisticated, lower manufacturing costs, the flange can be switched, the noise is small.
-
Series:
Parameter/ Specicification | Unit | PRF60 | PRF80 | PRF90 | PRF120 | PRF142 | ||
---|---|---|---|---|---|---|---|---|
Max.Torque | Nm | 1.5* Rated Torque | ||||||
Emerg. Braking Torque | Nm | 2* Rated Torque | ||||||
Max. Radial Torque | N | 240 | 400 | 450 | 1240 | 4800 | ||
Max. Axial Torque | N | 220 | 420 | 430 | 1000 | 4500 | ||
Torsional Stiffness | Nm/arcmin | 1.8 | 4.7 | 4.85 | 11 | 55 | ||
Max.Input Speed | rpm | 8000 | 6000 | 6000 | 6000 | 4500 | ||
Rated Input Speed | rpm | 4000 | 3500 | 3500 | 3500 | 2500 | ||
Noise | dB | <58 | <60 | <60 | <65 | <70 | ||
Aver. life | H | 20000 | ||||||
Full load-efficiency | % | L1≥96%, L2≥94% | ||||||
Backlash | P0 | L1 | arcmin | <3 | <3 | <3 | <3 | <3 |
L2 | arcmin | <5 | <5 | <5 | <6 | <6 | ||
P1 | L1 | arcmin | <6 | <6 | <6 | <8 | <8 | |
L2 | arcmin | <10 | <10 | <10 | <10 | <10 | ||
Rotary Interial | L1 | 3 | Kg.cm² | 0.46 | 0.77 | 1.73 | 12.78 | 21.4 |
4 | Kg.cm² | 0.46 | 0.77 | 1.73 | 12.78 | 21.4 | ||
5 | Kg.cm² | 0.46 | 0.77 | 1.73 | 12.78 | 21.4 | ||
7 | Kg.cm² | 0.41 | 0.65 | 1.42 | 11.38 | 17.6 | ||
10 | Kg.cm² | 0.41 | 0.65 | 1.42 | 11.38 | 17.6 | ||
L2 | 12 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | |
15 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
20 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
25 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
28 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
40 | Kg.cm² | 0.44 | 0.72 | 1.49 | 12.18 | 17.4 | ||
50 | Kg.cm² | 0.34 | 0.58 | 1.25 | 11.48 | 15.7 | ||
100 | Kg.cm² | 0.34 | 0.58 | 1.25 | 11.48 | 15.7 |
Parameter/Specification | PRF60 | PRF80 | PRF90 | PRF120 | PRF142 | ||
---|---|---|---|---|---|---|---|
Stage | Ratio | ||||||
Rated Torque (Nm) | L1 | 3 | 27 | 50 | 96 | 161 | 392 |
4 | 40 | 90 | 122 | 210 | 520 | ||
5 | 40 | 90 | 122 | 210 | 520 | ||
7 | 34 | 48 | 95 | 170 | 395 | ||
10 | 16 | 22 | 56 | 86 | 265 | ||
L2 | 9 | 27 | 50 | 96 | 161 | 392 | |
12 | 27 | 50 | 96 | 161 | 392 | ||
15 | 27 | 50 | 96 | 161 | 392 | ||
16 | 40 | 90 | 122 | 210 | 520 | ||
20 | 40 | 90 | 122 | 210 | 520 | ||
25 | 40 | 90 | 122 | 210 | 520 | ||
28 | 40 | 90 | 122 | 210 | 392 | ||
30 | 27 | 50 | 96 | 161 | 392 | ||
35 | 40 | 90 | 122 | 210 | 520 | ||
40 | 40 | 90 | 122 | 210 | 520 | ||
50 | 40 | 90 | 122 | 210 | 520 | ||
70 | 34 | 48 | 95 | 170 | 395 | ||
100 | 16 | 22 | 56 | 86 | 265 | ||
Weight (Kg) | L1 | 1.7 | 4.4 | 12 | 26.5 | ||
L2 | 1.9 | 5 | 14 | 29.6 |
PRF-60-L1
PRF-60-L2
PRF-80-L1
PRF-80-L2
PRF-90-L1
PRF-120-L1
PRF-120-L2
PM Series - Technical Parameters
Product Description
◆ First-stage reduction ratio can be done: 3,4,5,6,7,8,9,10
◆ Two do reduction ratio: 15 , 20,35,40,50,80,100
◆ Rotation ratio 3 ~ 100
◆ Accuracy 3 ~ 5arcmin
◆ Specific models are as follows: PM060 PM060-L1-3, PM060-L1-4, PM060-L1-5, PM060-L1-6, PM060-L1-7,
PM060-L1-8, PM060-L1-9, PM060-L1-10 PM060-L2-15,
PM060-L2-20, PM060-L2-35, PM060-L2-40, PM060-L2-50, PM060-L2-80, PM060-L2-100
Features:
Flange, single support structure:◆ More sophisticated, lower manufacturing costs, the flange can be switched, the noise is small.
-
Series:
Parameter/Specification | Unit | PM60 | PM90 | PM120 | PM140 | PM180 | PM220 | ||
---|---|---|---|---|---|---|---|---|---|
Max.Torque | Nm | 1.5* Rated Torque | |||||||
Emerg. Braking Torque | Nm | 2.5* Rated Torque | |||||||
Max. Radial Torque | N | 1530 | 3250 | 6700 | 9400 | 1450 | 50000 | ||
Max. Axial Torque | N | 630 | 1300 | 3000 | 4700 | 7250 | 35000 | ||
Torsional Stiffness | Nm/arcmin | 7 | 14 | 25 | 50 | 145 | 225 | ||
Max.Input Speed | rpm | 8000 | 8000 | 8000 | 6000 | 6000 | 4000 | ||
Rated Input Speed | rpm | 5000 | 4000 | 4000 | 3000 | 3000 | 2000 | ||
Noise | dB | ≤58 | ≤60 | ≤65 | ≤68 | ≤68 | ≤70 | ||
Aver. life | H | 20000 | |||||||
Full load-efficiency | % | L1≥95%, L2≥90% | |||||||
Backlash | P0 | L1 | arcmin | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 |
L2 | arcmin | ≤5 | ≤5 | ≤5 | ≤6 | ≤6 | ≤6 | ||
P1 | L1 | arcmin | ≤6 | ≤6 | ≤6 | ≤6 | ≤6 | ≤6 | |
L2 | arcmin | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ||
Rotary Interial | L1 | 3 | Kg.cm² | 0.16 | 0.61 | 3.25 | 9.21 | 28.98 | 69.61 |
4 | Kg.cm² | 0.14 | 0.48 | 2.74 | 7.54 | 23.67 | 54.37 | ||
7 | Kg.cm² | 0.13 | 0.45 | 2.62 | 7.14 | 22.48 | 50.97 | ||
8 | Kg.cm² | 0.13 | 0.45 | 2.6 | 7.14 | 22.48 | 50.88 | ||
9 | Kg.cm² | 0.13 | 0.42 | 2.59 | 7.08 | 22.4 | 50.73 | ||
10 | Kg.cm² | 0.13 | 0.4 | 2.57 | 7.03 | 22.51 | 50.56 | ||
L2 | 15 | Kg.cm² | 0.13 | 0.45 | 0.45 | 2.63 | 7.3 | 22.79 | |
20 | Kg.cm² | 0.13 | 0.45 | 0.45 | 2.63 | 7.3 | 22.79 | ||
35 | Kg.cm² | 0.13 | 0.45 | 0.45 | 2.43 | 7.1 | 22.59 | ||
40 | Kg.cm² | 0.13 | 0.45 | 0.45 | 2.43 | 6.92 | 21.83 | ||
50 | Kg.cm² | 0.13 | 0.4 | 0.4 | 2.39 | 6.92 | 21.83 | ||
80 | Kg.cm² | 0.13 | 0.4 | 0.4 | 2.39 | 6.72 | 21.65 | ||
100 | Kg.cm² | 0.13 | 0.4 | 0.4 | 2.39 | 6.72 | 21.6 |
Parameter/Specification | PM60 | PM90 | PM120 | PM140 | PM180 | PM220 | ||
---|---|---|---|---|---|---|---|---|
Rated Torque(Nm) | Stage | Ratio | ||||||
L1 | 3 | 30 | 50 | 120 | 280 | 800 | 1700 | |
4 | 45 | 85 | 210 | 440 | 800 | 1700 | ||
5 | 45 | 85 | 210 | 440 | 1000 | 2000 | ||
6 | 45 | 85 | 210 | 440 | 1000 | 2000 | ||
7 | 45 | 85 | 210 | 440 | 1000 | 2000 | ||
8 | 40 | 80 | 200 | 400 | 800 | 1700 | ||
9 | 30 | 60 | 140 | 300 | 700 | 1500 | ||
10 | 30 | 60 | 140 | 300 | 700 | 1500 | ||
L2 | 15 | 30 | 50 | 120 | 280 | 800 | 1700 | |
20 | 45 | 85 | 210 | 440 | 800 | 1700 | ||
35 | 45 | 85 | 210 | 440 | 1000 | 2000 | ||
40 | 45 | 85 | 210 | 440 | 800 | 1700 | ||
50 | 45 | 85 | 210 | 440 | 1000 | 2000 | ||
80 | 40 | 80 | 200 | 400 | 800 | 1700 | ||
100 | 30 | 60 | 140 | 300 | 700 | 1800 | ||
Protect Level | IP65 | |||||||
Environment Temp. | 45°C -- -15°C |
PM-60-L1
PM-60-L2
PM-90-L1
PM-90-L2
PM-120-L2
PM-180-L2
PVF Series - Technical Parameters
Product Description
◆ First, the model 60-120 Transmission ratio 3-100
◆ Second, the accuracy of 8 -15arcmin
◆ Third, the right angle output, installation length is small, stable and reliable
Features:
◆ Helical, Double Support, Integrated Planetary Frame,.◆ High Rigidity, High Torque, Bottom Backlash.
parameter/specification | Unit | PVF60 | PVF90 | PVF120 | ||
---|---|---|---|---|---|---|
Max.Torque | Nm | 1.5 | ||||
Emerg.Braking Torque | Nm | 2 | ||||
Max.Radial Torque | N | 240 | 450 | 1240 | ||
Max.Axial Torque | N | 220 | 430 | 1000 | ||
Torsional Stifffness | Nm/arcmin | 1.8 | 4.85 | 11 | ||
Max.Input Speed | rpm | 8000 | 6000 | 6000 | ||
Rated Input Speed | rpm | 4000 | 3500 | 3500 | ||
Noise | dB | <58 | <60 | <65 | ||
Aver.Life | h | 20000 | ||||
Full load-efficiency | % | l1≥95% L2≥92% | ||||
p1 | L1 | arcmin | ≤8 | ≤8 | ≤8 | |
L2 | arcmin | ≤12 | ≤12 | ≤12 | ||
P2 | L1 | arcmin | ≤16 | ≤16 | ≤16 | |
L2 | arcmin | ≤20 | ≤20 | ≤20 | ||
L1 | 3 | Kg.cm² | 0.46 | 1.73 | 12.78 | |
4 | Kg.cm² | 0.46 | 1.73 | 12.78 | ||
5 | Kg.cm² | 0.46 | 1.73 | 12.78 | ||
7 | Kg.cm² | 0.41 | 1.42 | 11.38 | ||
10 | Kg.cm² | 0.41 | 1.42 | 11.38 | ||
12 | Kg.cm² | 0.44 | 1.49 | 12.18 | ||
L2 | 15 | Kg.cm² | 0.44 | 1.49 | 12.18 | |
20 | Kg.cm² | 0.44 | 1.49 | 12.18 | ||
25 | Kg.cm² | 0.44 | 1.49 | 12.18 | ||
28 | Kg.cm² | 0.44 | 1.49 | 12.18 | ||
40 | Kg.cm² | 0.44 | 1.49 | 12.18 | ||
50 | Kg.cm² | 0.34 | 1.25 | 11.48 | ||
100 | Kg.cm² | 0.34 | 1.25 | 11.48 |
Parameter/Specification | PVF60 | PVF90 | PVF120 | ||
---|---|---|---|---|---|
Rated Torque(Nm) | stage | Ratio | |||
L1 | 3 | 27 | 96 | 161 | |
4 | 40 | 122 | 210 | ||
5 | 40 | 122 | 210 | ||
7 | 34 | 95 | 170 | ||
10 | 16 | 56 | 86 | ||
L2 | 9 | 27 | 96 | 161 | |
12 | 27 | 96 | 161 | ||
15 | 27 | 96 | 161 | ||
16 | 40 | 122 | 210 | ||
20 | 40 | 122 | 210 | ||
25 | 40 | 122 | 210 | ||
28 | 40 | 122 | 210 | ||
30 | 27 | 96 | 161 | ||
35 | 40 | 122 | 210 | ||
40 | 40 | 122 | 210 | ||
50 | 40 | 122 | 210 | ||
70 | 34 | 95 | 170 | ||
100 | 16 | 56 | 86 | ||
weight(kg) | L1 | 1.7 | 4.4 | 12 | |
L2 | 1.9 | 5 | 14 |
PVF-60-L1
PVF-60-L2
PVF-90-L1
PVF-90-L2
PVF-120-L1
PVF-120-L2
PT Series - Technical Parameters
Product Description
◆ C,D Section transmission ratio 3-9
◆ 5-15 arcmin
◆ Helical gear transmission, can transmit larger torque , low noise
◆ Integrated planetary structure, Double brace cage , high rigid
◆ Shell is die-casting forming, compact design
◆ Economic and pratical
Parameter/ Specification | 200W | 400W | 750W | |||||||
---|---|---|---|---|---|---|---|---|---|---|
S9C-200 | 5C-400 | S9C-400 | 3C-750 | 5C-750 | S9D-750 | |||||
Rated torque(Nm)Tn | 3.72 | 5.39 | 9.51 | 6.37 | 10.7 | 18.2 | ||||
Max.Torque | Nm | 11.3 | 16.2 | 28.5 | 19.3 | 32.1 | 54.7 | |||
Emerg. Braking Torque | Nm | 29.2 | 19.7 | 29.2 | 20.6 | 34.3 | 54.7 | |||
Max. Radial Torque | N | 1180 | 980 | 1180 | 784 | 980 | 1470 | |||
Max. Axial Torque | N | 588 | 1180 | 588 | 392 | 490 | 735 | |||
Max.Input Speed | rpm | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 | |||
Rated Input Speed | rpm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | |||
Noise | dB | <60 | <60 | <60 | <60 | <60 | <60 | |||
Aver. life | h | 20000 | ||||||||
Full load-efficiency | % | ≥96% | ||||||||
Backlash | P0 | arcmin | <5 | <5 | <5 | <5 | <5 | <5 | ||
P1 | arcmin | <15 | <15 | <15 | <15 | <15 | <15 | |||
Rotary Interial | Kg.cm² | 0.275 | 0.363 | 0.275 | 0.913 | 0.713 | 0.65 |
Parameter/ Specification | 200W | 400W | 750W | |||||||
---|---|---|---|---|---|---|---|---|---|---|
S9C-200 | 5C-400 | S9C-400 | 3C-750 | 5C-750 | S9D-750 | |||||
Rated torque(Nm)Tn | 3.72 | 5.39 | 9.51 | 6.37 | 10.7 | 18.2 | ||||
Max.Torque | Nm | 11.3 | 16.2 | 28.5 | 19.3 | 32.1 | 54.7 | |||
Emerg. Braking Torque | Nm | 29.2 | 19.7 | 29.2 | 20.6 | 34.3 | 54.7 | |||
Max. Radial Torque | N | 1180 | 980 | 1180 | 784 | 980 | 1470 | |||
Max. Axial Torque | N | 588 | 1180 | 588 | 392 | 490 | 735 | |||
Max.Input Speed | rpm | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 | |||
Rated Input Speed | rpm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | |||
Noise | dB | <60 | <60 | <60 | <60 | <60 | <60 | |||
Aver. life | h | 20000 | ||||||||
Full load-efficiency | % | ≥96% | ||||||||
Backlash | P0 | arcmin | <5 | <5 | <5 | <5 | <5 | <5 | ||
P1 | arcmin | <15 | <15 | <15 | <15 | <15 | <15 | |||
Rotary Interial | Kg.cm² | 0.275 | 0.363 | 0.275 | 0.913 | 0.713 | 0.65 |
PT-3C
PT-S9D-750
PT-S9C-200
